Industrial Strength Electric Power

Introducing the high energy density of lithium-ion batteries to a proven and rugged workhorse for unbeatable electric-powered performance.


Dependable Electronics + Lithium-ion Batteries

The high energy density of lithium-ion batteries provides the ability to quickly charge between resurfacings, maintaining power and eliminating the need for lengthy overnight recharging periods. Charge time is generally equivalent to work time. Recharge for about the same amount of time and you’re back on the ice. With the standard or optional extended capacity battery package the 450 can support a variety of arena schedules. The battery package is smaller and lighter weight. Zero-maintenance lithium-ion batteries are sealed and do not require watering. In addition to their improved resiliency and longer cycle life, lithium-ion batteries do not release gasses during the recharging process and are emission-free.

AC motors and controls introduce new efficiencies and virtually eliminate associated maintenance. Microprocessor controlled chargers communicate directly with the battery pack to optimize cell balancing and charging. The result: longer battery life. Proven and dependable Sevcon® Gen4 controls are built for tough industrial applications. On-board diagnostics provide management of machine functions and status updates.

The Model 450 combines decades of legendary electric performance and our industry-proven powertrain with lithium-ion powered AC motor and controls, providing a low maintenance option for your high maintenance surface.

Robust Powertrain and Hydraulics

The hydrostatic transmission affords unmatched power at any speed. The efficient accessory pump delivers full power and speed to the augers, even while the machine slows for corners. Full hydrodynamic braking with rear drum brakes for additional efficiency. Four-wheel drive and rugged Dana Spicer® axles combine with a hydrostatic transmission and a 64 hp electric motor, providing the most reliable powertrain in the industry.

With a compact wheelbase, the Model 450 enjoys a tighter turning radius, optimizing maneuverability. Its smaller footprint does not compromise the capacities afforded by the larger machines, with strong snow compaction and water tanks to support an efficient operation. Continuously variable hydrostatic pump and motor are axial-piston type, providing superior on-ice power with maximum drawbar pull. The direct shaft driven “piggy-back” mount ensures trouble-free service. Easy access high quality filters. The reliable and efficient hydraulic system provides a smooth and consistent resurfacing performance.

Quality Construction

Designed for the tough demands of an ice arena. Our machines are built by hand. One at a time. By skilled craftsmen dedicated to building the highest quality products in an industry known to put equipment to the test.

Robust welded steel tubing chassis contributes to the sound construction of the machine. The ergonomically designed operator’s compartment has well-placed controls. Unique to the 400 Series is foot pedal directional control of the machine. This doubles as a safety feature, stopping the machine if the operator’s foot leaves the accelerator pedal. Premium primer and paint, rust-free poly ice making water tank and stainless steel hardware afford corrosion resistance. Exceptional results from our unrivaled down pressure system which puts the power where you need it.

The Model 450 provides an emission-free electric powered machine capable of handling the formidable challenges of ice maintenance. Zamboni ice resurfacers have a well-deserved reputation for producing the finest sheet of ice, even after many years of use.
Nothing else is even close.

A Legacy of Innovation

Over seventy years ago, in 1949 Zamboni introduced the world’s first ice resurfacing machine. The first electric powered Zamboni ice resurfacers made their debut at the Squaw Valley Winter Olympic Games in February of 1960. As battery technology evolved, the 500 Series included electric powered production machines, setting the standard for electric resurfacing equipment by demonstrating the quality and reliability of our products.

The Model 450 provides an emission-free electric powered machine capable of handling the formidable challenges of ice maintenance. Enhancing our industry-proven powertrain with a lithium-ion powered AC motor and controls provides a low maintenance option for your high maintenance surface.

Zamboni ice resurfacers have a well-deserved reputation for producing the finest sheet of ice, even after many years of use. In the decades since those early introductions, we’ve proven our position as the industry leader, producing the most reliable and efficient ice resurfacing machines and equipment. Nothing else is even close.

Standard Features

  • 2 Year Warranty

  • 400 Micron Mesh Wash Water Deep Filter Bag

  • Chassis: Strong All Welded Steel Tubing

  • Conditioner Safety Guards

  • Digital Training and Reference Materials

  • Familiar Automobile-Style Foot Controls

  • Four-Wheel Drive

  • Full Hydrodynamic Braking

  • Guide Wheel

  • Headlights and Tail Light (for Off Ice Travel)

  • High Quality 10 and 25 Micron Filters

  • High Speed Vertical Auger

  • Hydraulic Oil Level Sight Gauge

  • Load Sensing Motor Governor

  • Motor: High Efficiency Permanent

  • Magnet AC

  • Motor Control: Sevcon Motor Control

  • On-Dash Diagnostics

  • Parking Brake

  • Power Steering

  • Premium Polyester Felt Spreader Towel

  • Replaceable Poly Conditioner Side Plates

  • Rugged Dana Spicer® Axles

  • Snow Tank Safety Stand

  • Spare Tire and Wheel

  • Steering Wheel Spinner Knob

  • Touch-Up Paint Kit

  • Tungsten Carbide Studded Tires

  • Under Seat Storage

  • Wide Spectrum of Premium Automotive Paint Colors

Options

  • Automatic Snow Breaker

  • Back Up Alarm

  • Battery and Motor Diagnostic Computer Interface Tool

  • Blade Change System

  • Chrome Wheels

  • Conditioner: Galvanized

  • Electric Water Level Gauge

  • Fire Extinguisher

  • Heated Ergonomic Comfort Design Seat
    • Armrest
    • Seatbelt

  • IceCaps® Wheel Advertising System

  • Integrated Auger Washout System


  • Level-Ice™

  • Rotating Beacon Light

  • Side Snow Tank Dump

  • Snow Melting Kit

  • Snow Tank Dump Height Restriction

  • Snow Tank Light

  • Snow Tank Non-Stick Liner

  • Stainless Steel Water Distribution Pipe

  • Tire Wash System

  • Wash Water to Ice Making Water Transfer

  • Water Level Sight Gauge

  • Zamboni Connect™ System

  • Zamboni Power Board Brush™ System
